CAIZER 2 POST HOISTS - T53+ (ELECTRIC LOCK)
CAIZER T53 PLUS PRODUCT DETAILS
5300kg Clear Floor
Non-leakage fully sealed cylinders with German performance seals.
Wire rope synchronisation.
Electric safety lock release with optional sensors.
Overall height adjustable (3 settings).
Overall width adjustable (2 settings).
Standard foot protection guard with tool-tray.
Dual upper limit switches on post and cross member.
Telescopic lift pads with standard 100mm pad extensions.
Top quality Korean hydraulic unit with Italian 3kw fast spin motor.
SPECIFICATIONS:
Model : Caizer T53+
Lifting Capacity : 5,300 Kg
Max. Lifting Height : 1,890 ~2,030mm (includes 100mm adaptor)
Stroke : 1,800mm
Lifting Time : Approx. 30 ~ 45 sec
Lowering Time : Approx. 30 ~ 45 sec
Power Supply & Motor : 3kw 415v, 50Hz
Operating Method : Control box and cable remote control
Net Weight : About 950 Kg
